Positive Displacement Pump Types

The Hydraulic Institute standardizes rotodynamic and positive displacement [Link] pump types, definitions and nomenclature. The description for each rotodynamic pump type, and the related industry standard are included.

Positive displacement pumps are divided into reciprocating types, which use pistons, plungers and diaphragms, and rotary types, which utilize meshing components, such as, screws, gears, lobes and vanes.

Index

Pump Types - Rotary Positive Displacement
Pump Types - Reciprocating Positive Displacement

Pump Types - Rotary Positive Displacement
Pump Types - Rotary Positive Displacement
Acronym Pump Description Reference
Circumferential piston ANSI/HI 3.1-3.5
Gear type - sealless ANSI/HI 4.1-4.6
Gear, external ANSI/HI 3.1-3.5
Gear, internal with crescent ANSI/HI 3.1-3.5
Gear, internal without crescent ANSI/HI 3.1-3.5
Lobe, single ANSI/HI 3.1-3.5
Lobe, three ANSI/HI 3.1-3.5
Piston, axial ANSI/HI 3.1-3.5
Screw type - Sealless ANSI/HI 4.1-4.6
Screw, single (progressing cavity) ANSI/HI 3.1-3.5
Screw, three (untimed) ANSI/HI 3.1-3.5
Screw, two (timed) ANSI/HI 3.1-3.5
Tube, flexible (peristaltic) ANSI/HI 3.1-3.5
Vane type - sealless ANSI/HI 4.1-4.6
Vane, flexible ANSI/HI 3.1-3.5
Vane, sliding ANSI/HI 3.1-3.5

Pump Types - Reciprocating Positive Displacement
Pump Types - Reciprocating Positive Displacement
Acronym Pump Description Reference
AOD Air-operated - Bellows - simplex or duplex ANSI/HI 10.1-10.6
AOD Air-operated - Diaphragm - simplex or duplex ANSI/HI 10.1-10.5
Air-operated - piston
Air-operated - plunger
CVMP Controlled volume metering - diaphragm ANSI/HI 7.1-7.5
CVMP Controlled volume metering - piston ANSI/HI 7.1-7.5
Piston - direct acting - single or double acting - simplex or duplex HI 8.1-8.5
Plunger - direct acting - single or double acting - simplex or duplex HI 8.1-8.5
Piston - single or double acting - simplex or multiplex HI 6.1-6.5
Plunger- single or double acting - simplex or multiplex HI 6.1-6.5

Last updated on August 31, 2026
